TuffStuff Fitness – Proformance Plus 4-Station Jungle Gym (PPMS-4000)

Description

4-Station Jungle Gym

The Proformance Plus 4-Station Jungle Gym (PPMS-4000) is a modular system that includes four 200 lbs. steel weight stacks, with the option to upgrade to 300 lbs. weight stacks.  Highly customizable, the Jungle Gym allows you to choose the exercise stations, positioning, frame and upholstery colors that best suit your facility.

The 4-Station Jungle Gym is designed for full commercial use.  Steel plate corner braces reinforce the main frame for maximum structural stability.  The frame, welds, cams, and weight plates are all backed by TuffStuff’s 10 year Commercial Warranty (view Additional Information section to learn more).

System as shown:  (1) Lat Pulldown; (1) Low Row;  (1) Tricep Pressdown; (1) Adjustable High/Low Station



PROFORMANCE PLUS CUSTOMIZATION

The Proformance Plus 4-Station Jungle Gym’s finish colors, upholstery and embroidered wear covers may be personalized.  Add your logo to further enhance your company’s branding.  Factory assembly is also available for Proformance Plus strength equipment.



Frame Colors:

Custom two tone finish offers choice of seven primary colors: (1) Charcoal Texture (2) Platinum Sparkle (3) Red Baron II (4) Sky White (5) Twilight Blue (6) Matte Black (7) Wrinkle Black

Note: Finishes as shown are close representations of the actual powder coat colors, and MUST NOT be used for an exact match of the color.



Upholstery Colors:

Proformance Plus upholstery is custom crafted from Premium Bolta Sport vinyl with a PreFixx protective finish.  It is mildew resistant, anti-microbial, oil and sulfide stain resistant and resists UV lightfastness.  Meets or exceeds most flammability test requirements.  All upholsteries are double-stitched with “hidden” borders.

Note: Color samples as shown are close representations of the actual vinyl and finish colors, and MUST NOT be used for an exact match of the color.  Always request actual vinyl samples from your dealer or TuffStuff Sales Representative.



TUFFSTUFF COMMERCIAL STRENGTH

Since 1971 TuffStuff Fitness International has focused on one thing, the design and development of premium strength equipment.

Over the last five decades, TuffStuff has manufactured the highest quality strength equipment and set the industry standards against which all other equipment is measured.  TuffStuff’s craftsmanship is recognized worldwide, and their products are sold across the United States, Canada, Mexico and in more than thirty other countries.

Today TuffStuff is the only fitness company in the United States with a full-service manufacturing facility, capable of producing every product they sell.  Every design and engineering process begins in Chino, California – from concepts to prototypes, testings and design refinements.  As a result, TuffStuff has greater flexibility to customize products, faster turn around times, and maintains a higher level of quality control than competitors.

TuffStuff’s commercial strength equipment is built to exacting standards, with full commercial-grade components including 7 and 11-gauge tubular steel, inert-gas MIG welded construction, and certified USA-made cables.  Whether you are looking to outfit the world’s finest health club, or you just need a single equipment station that will stand the test of time, with TuffStuff you will receive unmatched product quality and exceptional support.

Weight	1520 lbs
Dimensions	79 × 138 × 90 in
Commercial Warranty	COMMERCIAL WARRANTY 10 YEARS: Frames, welds, cams and weight plates. 5 YEARS: Pivot bearings, pulleys, bushings, gas-shocks, and guide rods. 1 YEAR: Belts, linear bearings and pull-pin components. 6 MONTHS: Upholstery, cables, finish and rubber grips. ALL OTHER PARTS not mentioned, one year from the date of purchase to the original purchaser.
Frame	Main frame – 2×4” 11-gauge 120 wall oval tubular steel with a combination of 2” round and other 11-gauge tubular steel. All welded construction conforming with all Structural Welding Code-Steel Standards and Specifications.
Padding	High density 1” thick 3 lbs. rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.
Cables & Belts	Cable driven units – USA-Made/Certified 3/16” and 1/4” EXERFLEX PRO® high performance fitness cable rated at 4200 lbs. tensile strength. Belt driven units: reinforced Kevlar® belts, rated at 4400 lbs. tensile strength.
Finish	Powder coat finish baked at 400ºF and carefully monitored to ensure complete curing. Custom two tone finish offers choice of six primary colors combined with Charcoal Texture accents. Custom colors available, please inquire with your sales representative.
Upholstery	Premium Bolta Sport vinyl with PreFixx, formulated to resist bacteria, stains, mildew, oil and UV stabilized pigments. Meets most flammability test requirements. All upholsteries are double-stitched with “hidden” borders. Bolta Sport color swatches are available upon request. Sixteen standard colors. Custom colors are available – please inquire with your sales representative.
Weight Stack	Black painted solid steel weight plates with self aligning low friction sleeves. Four (4) 200 lbs. steel weight stacks. (Optional: 300 lbs. steel weight stacks available)
Other Specs	GUIDE RODS: 3/4” solid steel 1045 (tgp) highly polished hard chrome finish. ADJUSTMENT PINS: 1/2” and 5/8” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength. BEARINGS: 1” solid stainless steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots. PULLEYS: Combination wide grove fiberglass reinforced nylon pulleys on belt-driven system and solid aluminum pulleys on cable units. CAMS: Charcoal Texture powder coat solid aluminum variable resistance cam designed specifically for each machine. FASTENERS: All frame bolts and nuts are 3/8” and 1/2” blue zinc plated grade 8 and up. Meets ANSI specifications. CUSTOM STABILIZER FEET: Heavy-duty molded rubber base feet insure stability, prevent equipment movement, and may be bolted to the floor. SELECTOR WEIGHT PINS: Weight pins are solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss.
